COURSER Toro Greensmaster 3000, 3100, 3200/3200-D & 3250-D 4-Bolt 11-Blade Cutting Head Rebuild Kit – Fits Cutting Units 04480 & 04481 – Complete 3-Head Set

A BIG SAVINGS compared with purchasing the included components separately.

This complete COURSER rebuild kit contains the main cutting and service components required to overhaul three Toro Greensmaster 4-bolt cutting heads, Models 04480 and 04481, and rebuild them in an 11-blade configuration.

These cutting units were used across compatible Toro Greensmaster machines, including the Greensmaster 3000, 3100, 3200, 3200-D and 3250-D, depending on the machine year and cutting-unit configuration.

Kit includes

• 3 × AM94-8037 — COURSER 11-blade cutting reels
• 6 × AM93-2489 — reel bearings, 2 per cutting head
• 6 × R94-8908 — reel seals, 2 per cutting head
• 3 × R94-4543 — flat reel springs, 1 per cutting head
• 3 × R94-4544 — reel spacers, 1 per cutting head
• 3 × R32120-37 — internal reel retaining rings, 1 per cutting head
• 3 × AM93-4263 — COURSER 21-inch Tournament Cut bedknives, 3 mm+, 13-hole
• 40 × AM119-4151 — replacement bedknife screws, including 39 required for the three bedknives and 1 spare

The supplied 11-blade reels and AM93-4263 Tournament Cut bedknives are designed for mowing heights of approximately 3 mm and above. This combination provides a close, clean and consistent finish for golf greens, tees and other closely maintained fine-turf surfaces.

Fits Toro Greensmaster models including

When fitted with 4-bolt cutting units 04480 or 04481:

• Toro Greensmaster 3000
• Toro Greensmaster 3100
• Toro Greensmaster 3200
• Toro Greensmaster 3200-D
• Toro Greensmaster 3250-D

Compatibility is determined by the cutting-unit model number, rather than the traction-unit model alone.

Cutting-unit information

• 04480 was originally supplied as an 8-blade 4-bolt cutting unit
• 04481 was originally supplied as an 11-blade 4-bolt cutting unit

This kit supplies three 11-blade reels, allowing compatible Model 04480 cutting heads to be rebuilt in the same 11-blade configuration used by Model 04481.

Important compatibility information

Before ordering, confirm:

• Cutting-unit Model 04480 or 04481
• Toro 4-bolt cutting-head configuration
• The supplied 11-blade configuration suits the intended mowing application
• The 3 mm+ Tournament Cut bedknife suits the required cutting height
• The existing reel, bearing, seal, spring, spacer and retaining-ring arrangement matches the parts supplied

This kit rebuilds a complete set of three cutting heads.

It does not suit later Toro DPA or Single Point Adjustment cutting units, which use different reel, bearing, seal and adjustment arrangements.

COURSER Premium guaranteed products are replacement parts designed to fit and replace corresponding OEM parts. OEM names, trademarks and part numbers are used for identification and compatibility reference only.
